线束设备系列/HARNESS EQUIPMENT SERIES

HBQ-K602 FUSE BOX CRIMPING MACHINE

Product characteristics: ●The machine takes the commercial gray as the basic color, the overall structure is simple and generous; ●C/T:1S/PCS; ●Separate display perfectly displays visual detection and pressure curves; ●Friendly PC interface enhances the visibility and operability.

Product information:Product videos, instructions, pictures

Product overview Product characteristics technical parameter Related products

HBQ-K602 fuse box crimping machine is mainly used in automotive wiring harness industry. It adopts visual and three-axis servo precise crimping, which can realize the detection of wrong and missing assembly of products and the output of accurate pressure waveform.
Action process: manual feeding-code scanning-start-camera detection-servo crimping-pressure sensor output curve-manual unloading after crimping.


●The machine takes the commercial gray as the basic color, the overall
    structure is simple and generous;
●C/T:1S/PCS;
●Separate display perfectly displays visual detection and pressure curves;
●Friendly PC interface enhances the visibility and operability.


Dimensions(mm)

1200(L)*1000(W)*1800(H) Customs available upon request

Power Supply

220V

Motor

Panasonic 400W

Visual CCD

Shooting speed 3S/time

Pressure Monitoring

Real-time

Air Supply

0.5MPa-0.7MPa

Safety curting

Keyence level 1
