CSC-6 Sample Wire Harness Intelligent Test System
Sample wire harness intelligent test system is a dedicated test system for sample wire teams, independently developed by our company. The system consists of two parts: the upper computer and the lower computer. The upper computer software is responsible for monitoring and management, with comprehensive functions covering data acquisition, processing, storage, and user interaction. The lower computer hardware interacts with the detected object, accurately receiving instructions and efficiently executing test tasks. Compared to traditional detection methods, this intelligent sample wire test system has significant advantages. It not only greatly improves detection efficiency but also fully guarantees the reliability of test results. The system has been carefully designed with a user-friendly human-computer interaction interface, providing users with an intuitive and convenient operation experience. In terms of program editing, a pipeline-style workflow has been adopted, greatly facilitating employee operation and use, reducing operational difficulty, and improving work efficiency. See details
CSC-6 Sample Wire Harness Intelligent Test System
TEST MODULE
The test modules are used to test the conductivity, water resistance, secondary locks or snaps, covers and other accessories of the wire harness connectors for missing and in place. Test modules can be classified according to module structure and functio See details
TEST MODULE
HCS-CBLA Integrated Tesing Table
HCS-CBLA Integrated Tesing Table is used for the insertion and extraction force test of the charging port of wire harness of EV charging bases. Meanwhile, it has the functions of testing the continuity, airtightness, loop resistance, temperature-sensitive resistance, withstand voltage, insulation resistance, extension length of the electronic lock, ambient light, etc. of the products. And by quickly replacing the tooling fixtures, it can meet the comprehensive functional tests of different products (national standard AC/DC, European standard AC/DC, etc.), which greatly improves the adaptability and utilization rate of the equipment, reduces the production cost, and shortens the product development cycle. See details
HCS-CBLA Integrated Tesing Table
HCS-CBL-A Vertical plug-in charging testing table
HCS-CBL-A series Vertical plug-in charging testing table is used for testing the insertion and extraction force of EVs wire harness charging docks. It adopts a layout where the gun head is above and the product is below. The gun head moves from top to bottom for insertion and extraction testing. Moreover, it can meet the relevant testing requirements of different products (GB AC/DC, EU AC/DC, etc.) by quickly changing the fixture, greatly improving the adaptability and utilization rate of the equipment, reducing production costs, and shortening product development cycles. See details
HCS-CBL-A Vertical plug-in charging testing table
HCS-CBL-B Plug-in Charging Testing Table
HCS-CBL-B series plug-in charging testing table is designed for testing the insertion and extraction force of EVs wire harness charging docks. It adopts a layout where the gun head is positioned below and the product is above. The gun head moves from bottom to top for insertion and extraction testing. Additionally, it can quickly change tooling fixtures to accommodate testing of different products (such as GB AC/DC, EU AC/DC, etc.), greatly enhancing equipment adaptability and utilization, while reducing production costs and shortening product development cycles. See details
HCS-CBL-B Plug-in Charging Testing Table
HCSA-L Torque EV High Voltage Wire Harness Testing Table
HCSA-L Torque EV High Voltage Wire Harness Testing Table is an installation and detection machine used in the wire harness industry that integrates clip installation and torque tightening. It overcomes the problem of low efficiency caused by the alternate use of two separate detection machines for clips and torque tightening. With seamless connection, it significantly improves the production efficiency of high - voltage wire harnesses, reduces labor costs, saves equipment usage area and procurement costs. See details
HCSA-L Torque EV High Voltage Wire Harness Testing Table
